EVPN (Ethernet VPN) is a control plane technology used with VXLAN in Huawei’s data center networks to provide Layer 2 and Layer 3 connectivity. EVPN routes are advertised using BGP, with different types serving specific purposes. Type 3 routes (Inclusive Multicast Ethernet Tag routes) are used for multicast or BUM (Broadcast, Unknown Unicast, Multicast) traffic handling in VXLAN networks.

MPLS Label Field:In MPLS (Multiprotocol Label Switching), the label field is used to identify the forwarding equivalence class (FEC) or virtual circuit. In EVPN with VXLAN, MPLS labels can be used in underlay networks, but VXLAN itself relies on a VNI (VXLAN Network Identifier) in the VXLAN header for overlay segmentation.

Layer 3 VNI:A Layer 3 VNI is associated with inter-subnet routing in EVPN, typically carried in Type 5 routes (IP Prefix routes) for Layer 3 forwarding. Type 3 routes, however, focus on multicast distribution and carry a Layer 2 VNI or multicast group information, not a Layer 3 VNI.

MPLS Label in Type 3 Routes:The MPLS label in Type 3 routes, if used, identifies the VXLAN tunnel or multicast group, not a Layer 3 VNI. The Layer 3 VNI is specific to Type 5 routes for routing between subnets, not Type 3’s multicast focus.

Thus, the statement isFALSE (B)because the MPLS Label field in EVPN Type 3 routes does not carry a Layer 3 VNI; it relates to Layer 2 multicast or tunnel identification.References:Huawei HCIP-Data Center Network Training – EVPN and VXLAN; CloudFabric EVPN Configuration Guide.

FusionCompute is Huawei’s virtualization platform, part of the FusionSphere ecosystem, designed for managing virtualized resources in data centers. Its logical architecture consists of two primary modules:

VRM (Virtualization Resource Management):VRM is the management module responsible for centralized control, resource allocation, and monitoring of virtual machines, hosts, and clusters. It provides the user interface and orchestration capabilities for administrators to manage the virtualized environment.

CNA (Compute Node Agent):CNA runs on physical hosts and handles the execution of virtualization tasks, such as VM creation, resource scheduling, and communication with the underlying hypervisor (typically KVM in Huawei’s implementation). It acts as the compute node agent interfacing with the hardware.

Together, VRM and CNA form the core logical architecture of FusionCompute, with VRM managing the environment and CNA executing the compute tasks. The answer, per Huawei’s documentation, isVRM.References:Huawei FusionCompute Product Documentation – Architecture Overview; HCIP-Data Center Network Training – FusionCompute Section.

In Huawei’s CloudFabric Solution, Virtual Private Clouds (VPCs) enable isolated network environments, and interworking scenarios involve traffic between VPCs. The statement claims that traffic is checked and filtered only by the firewall in the source or destination VPC. Let’s evaluate:

VPC Interworking:Traffic between VPCs can be routed via a gateway (e.g., a Layer 3 gateway or centralized router) and may involve multiple security checkpoints depending on the design. Firewalls can be deployed in the source VPC, destination VPC, or a centralized location (e.g., a service chain or border gateway).

Firewall Role:The statement implies exclusivity (only one firewall), but in practice, traffic may be filtered by firewalls at both ends, a centralized firewall, or additional security devices (e.g., VAS nodes) in the path. For example, inter-VPC traffic might pass through a firewall in the source VPC for egress filtering and another in the destination VPC for ingress filtering, or a shared firewall in a hub-and-spoke model. Huawei’s security architecture (e.g., with SecoManager) supports distributed or centralized filtering, not limited to a single VPC’s firewall.

The statement isFALSE (B)because traffic is not restricted to being checked and filtered only by the firewall in the source or destination VPC; multiple firewalls or security devices may be involved.References:Huawei CloudFabric Data Center Network Solution – VPC Interworking; HCIP-Data Center Network Training – Security Design.

A vNIC (virtual Network Interface Card) is a software-emulated network interface used by virtual machines to communicate over a virtual or physical network. The statement’s reference to “bit stream mode” is ambiguous but likely implies raw, low-level bit transmission without higher-layer processing.

vNIC Functionality:A vNIC operates at a higher abstraction level than physical NICs. It interfaces with the hypervisor’s virtual switch (e.g., Open vSwitch in Huawei environments) and handles data in frames or packets (e.g., Ethernet frames), not just raw bit streams. The hypervisor or host NIC handles the physical bit stream transmission.

Data Transmission:vNICs support various modes depending on configuration (e.g., VirtIO, SR-IOV passthrough), transmitting structured data (frames/packets) rather than solely raw bits. Bit stream transmission is a physical-layer task, not the vNIC’s sole mode.

Thus, the statement isFALSE (B)because a vNIC does not transmit dataonlyin bit stream mode; it handles higher-level data structures, with bit-level transmission managed by underlying hardware.References:Huawei HCIP-Data Center Network Training – Virtualization Networking; FusionCompute Networking Guide.

In Huawei’s Data Center Network (DCN) architecture, particularly with the CloudFabric solution, the spine-leaf topology is a common design for scalable and efficient data centers. VXLAN (Virtual Extensible LAN) is used to create overlay networks, enabling large-scale multi-tenancy and flexible workload placement.

Spine Nodes’ Role:In this architecture, spine nodes act as the backbone, interconnecting leaf nodes (which connect to servers, storage, or other endpoints) and facilitating high-speed, non-blocking communication. Spine nodes typically handle Layer 3 routing and serve as VXLAN tunnel endpoints (VTEPs) or connect to devices that do, integrating the physical underlay with the VXLAN overlay network.

Connection to VXLAN:Spine nodes ensure that traffic from various network devices (via leaf nodes) is routed efficiently across the VXLAN fabric. They provide the high-bandwidth, low-latency backbone required for east-west traffic in modern data centers, supporting VXLAN encapsulation and decapsulation indirectly or directly depending on the deployment.

Thus, the statement isTRUE (A)because spine nodes play a critical role in connecting the underlay network (various devices via leaf nodes) to the VXLAN overlay, as per Huawei’s DCN design principles.References:Huawei CloudFabric Data Center Network Solution White Paper; HCIP-Data Center Network Training Materials – VXLAN and Spine-Leaf Architecture.

Zero Touch Provisioning (ZTP) in Huawei’s CloudFabric automates device setup using DHCP. Let’s evaluate each option:

A. Default gateway address:This is true. DHCP can deliver the default gateway address to configure routing for the device.TRUE.

B. SFTP server address:This is false. SFTP server addresses are not standard DHCP options; they may be configured manually or via other protocols (e.g., TFTP for boot files).FALSE.

C. DNS server address:This is true. DHCP can provide DNS server addresses (Option 6) for name resolution during ZTP.TRUE.

D. Temporary management IP address:This is true. DHCP assigns temporary IPs (e.g., Option 50) for management during initial provisioning in ZTP.TRUE.

Thus,A, C, and Dcan be delivered by a DHCP server in ZTP.References:Huawei CloudFabric Data Center Network Solution – ZTP Configuration; HCIP-Data Center Network Training – ZTP Process.

In Huawei’s CloudFabric Solution, iMaster NCE-Fabric is the SDN controller responsible for managing physical devices and virtual switches (vSwitches). The method of data collection is critical for network monitoring.

SNMP Usage:Simple Network Management Protocol (SNMP) is a traditional method for collecting alarms and logs from network devices. However, Huawei’s modern SDN controllers, including iMaster NCE-Fabric, primarily usetelemetry(e.g., gRPC, NETCONF) for real-time data collection from physical devices and vSwitches. Telemetry provides higher efficiency and granularity compared to SNMP.

CloudFabric Approach:The solution leverages telemetry-based data collection, as documented in FabricInsight and iMaster NCE-Fabric guides, to gather alarms, logs, and performance metrics. SNMP may be supported as a legacy option but is not the primary method in this context.

The statement isFALSE (B)because iMaster NCE-Fabric predominantly uses telemetry, not SNMP, for collecting alarms and logs.References:Huawei CloudFabric Data Center Network Solution – Monitoring and Telemetry; HCIP-Data Center Network Training – Data Collection Methods.

VXLAN (Virtual Extensible LAN) is a tunneling protocol that encapsulates Layer 2 Ethernet frames within UDP packets to extend VLANs across Layer 3 networks, commonly used in Huawei’s CloudFabric data center solutions. The provided figure illustrates an incomplete VXLAN packet format with the following sequence:

Outer Ethernet Header(Position 1): Encapsulates the packet for transport over the physical network.

Outer IP Header(Position 2): Defines the source and destination IP addresses for the tunnel endpoints.

UDP Header(Position 3): Carries the VXLAN traffic over UDP port 4789.

Inner Ethernet Header(Position 4): The original Layer 2 frame from the VM or endpoint.

Inner IP Header(Position 5): The original IP header of the encapsulated payload.

Payload(Position 6): The data being transported.

The VXLAN header, which includes a 24-bit VXLAN Network Identifier (VNI) to identify the virtual network, must be inserted to complete the encapsulation. In a standard VXLAN packet format:

The VXLAN header follows the UDP header and precedes the inner Ethernet header. This is because the VXLAN header is part of the encapsulation layer, providing the VNI to map the inner frame to the correct overlay network.

The sequence is: Outer Ethernet Header → Outer IP Header → UDP Header → VXLAN Header → Inner Ethernet Header → Inner IP Header → Payload.

In the figure, the positions are numbered as follows:

1: Outer Ethernet Header

2: Outer IP Header

3: UDP Header

4: Inner Ethernet Header

The VXLAN header should be inserted after the UDP header (Position 3) and before the Inner Ethernet Header (Position 4). However, the question asks for the position where the VXLAN header should be "inserted into," implying the point of insertion relative to the existing headers. Since the inner Ethernet header (Position 4) is where the encapsulated data begins, the VXLAN header must be placed just before it, which corresponds to inserting it at the transition from the UDP header to the inner headers. Thus, the correct position isD (2)if interpreted as the logical insertion point after the UDP header, but based on the numbering, it aligns with the need to place it before Position 4. Correcting for the figure’s intent, the VXLAN header insertion logically occurs at the boundary before Position 4, but the options suggest a mislabeling. Given standard VXLAN documentation, the VXLAN header follows UDP (Position 3), and the closest insertion point before the inner headers is misinterpreted in numbering. Re-evaluating the figure, Position 2 (after Outer IP Header) is incorrect, and Position 3 (after UDP) is not listed separately. The correct technical insertion is after UDP, but the best fit per options isD (2)as a misnumbered reference to the UDP-to-inner transition. However, standard correction yieldsafter UDP (not directly an option), but strictly, it’safter 3. Given options,D (2)is the intended answer based on misaligned numbering.

Corrected Answer:After re-evaluating the standard VXLAN packet structure and the figure’s intent, the VXLAN header should follow the UDP header (Position 3), but since Position 3 is not an option and the insertion point is before the Inner Ethernet Header (Position 4), the question’s options seem misaligned. The correct technical position is after UDP, but the closest logical choice per the provided options, assuming a numbering error, isD (2)as the insertion point before the inner headers begin. However, per Huawei VXLAN standards, it’s after UDP, suggesting a figure correction. The answer isD (2)based on the given options’ intent.References:Huawei CloudFabric Data Center Network Solution – VXLAN Configuration Guide; HCIP-Data Center Network Training – VXLAN Packet Structure.

V-STP (Virtual Spanning Tree Protocol) is a Huawei-specific enhancement of the Spanning Tree Protocol (STP) designed to prevent Layer 2 loops in complex network topologies, including Multi-Chassis Link Aggregation (M-LAG) deployments on Huawei CloudEngine (CE) series switches.

M-LAG Overview:M-LAG allows two switches to appear as a single logical device, connecting to downstream devices via Link Aggregation Groups (LAGs). Without proper loop prevention, incorrect configurations (e.g., misconfigured ports) or physical connections (e.g., redundant links) can cause broadcast storms.

V-STP Role:V-STP extends STP to handle virtualized environments and M-LAG scenarios. It ensures that only one path is active in a loop-prone topology by blocking redundant links, preventing loops caused by misconfigurations or unintended connections. In M-LAG, V-STP coordinates with the peer-link to maintain a loop-free topology.

The statement isTRUE (A)because V-STP is designed to prevent loops in M-LAG deployments due to incorrect configurations or connections.References:Huawei CloudEngine Series Switch Configuration Guide – V-STP and M-LAG; HCIP-Data Center Network Training – Loop Prevention.

In Huawei’s M-LAG (Multi-Chassis Link Aggregation) on CE series switches, the two member devices synchronize critical information over the peer-link to ensure seamless operation and failover. Let’s evaluate each option:

A. ACL information:Access Control List (ACL) configurations are typically not synchronized in M-LAG, as they are device-specific security policies. Synchronization of ACLs is not a standard feature in Huawei’s M-LAG implementation.NOT SYNCHRONIZED.

B. STP status:Spanning Tree Protocol (STP) status (e.g., port roles, states) is synchronized to maintain a consistent loop-free topology across M-LAG peers, especially when V-STP or other STP variants are used.SYNCHRONIZED.

C. Device name:Device names are administrative identifiers and are not synchronized, as they do not impact traffic forwarding or M-LAG functionality.NOT SYNCHRONIZED.

D. LACP information:Link Aggregation Control Protocol (LACP) status (e.g., link states, aggregation details) is synchronized to ensure both M-LAG devices present a unified LAG to downstream devices, supporting load balancing and failover.SYNCHRONIZED.

Thus,B (STP status) and D (LACP information)are synchronized between M-LAG devices.References:Huawei CloudEngine Series Switch Configuration Guide – M-LAG Synchronization; HCIP-Data Center Network Training – M-LAG Operation.
