BGP will be configured on the T0 SR. Connect to the VRF for the T0 SR and run get bgp neighbor once connected to it. https://docs.vmware.com/en/VMware-Validated-Design/5.1/sddc-deployment-of-vmware-nsx-t-workload-domains-with-multiple-availability-zones/GUID-8BD4228A-75C6-4C60-80B4-538D4297E11A.html

For the BGP configuration on NSX-T, the Tier-0 Service Router (SR) is typically where BGP is configured. To check the BGP neighbor status:

Connect to the VRF for the T0 SR, which is VRF 3 based on the provided output.

Run the command to get BGP neighbor status once connected to it.

The four types of role-based access control (RBAC) permissions are Read, None, Full access, and Execute1. Read permission allows the user to view the configuration and status of the system. None permission denies any access to the system. Full access permission grants all permissions including Create, Read, Update, and Delete (CRUD). Execute permission includes Read and Update permissions1. Auditor, Enterprise Admin, and Network Admin are not types of permissions, but types of roles that have different sets of permissions. References: NSX Features

There are four types of permissions. Included in the list are the abbreviations for the permissions that are used in the Roles and Permissions and Roles and Permissions for Manager Mode tables.

Full access (FA) - All permissions including Create, Read, Update, and Delete

Execute (E) - Includes Read and Update

Read (R)

None

NSX-T Data Center has the following built-in roles. Role names in the UI can be different in the API. In NSX-T Data Center, if you have permission, you can clone an existing role, add a new role, edit newly created roles, or delete newly created roles.

Role-Based Access Control (vmware.com)

According to the VMware Knowledge Base article 1, the CLI command to set the log level of the NSX Manager to debug mode is set service manager logging-level debug. This command can be used when the NSX UI is inaccessible or when troubleshooting issues with the NSX Manager1. The other commands are incorrect because they either use a wrong syntax or a wrong service name. The NSX Manager service name is manager, not nsx-manager2. The log level parameter is logging-level, not log-level3.

https://kb.vmware.com/s/article/55868

According to the VMware NSX Documentation4, the set auth-policy command is used to change the authentication policy settings for local users, such as password length, lockout period, and maximum authentication failures. The other commands are either used to view the authentication policy settings (B), change the CLI session timeout (A), or change the hardening policy settings ©.

According to the VMware documentation1, the clock icon appears on the firewall policy section that you want to have a time window. By clicking the clock icon, you can create or select a time window that applies to all the rules in that policy section. The other options are incorrect because they either do not exist or are not related to the time-based rule feature. There is no option to set a time-based rule in the rule itself, as it is a policy-level setting. There is also an option to set a time-based rule in the NSX UI, so it does not require using the command line interface.

https://docs.vmware.com/en/VMware-NSX/4.1/administration/GUID-8572496E-A60E-48C3-A016-4A081AC80BE7.html

A group is a logical construct that represents a collection of objects in NSX, such as segments, segment ports, virtual machines, IP addresses, MAC addresses, tags, or security policies. A group can be used to define dynamic membership criteria based on various attributes or filters. A group can also be used as the scope of a distributed firewall rule, which means that the rule will apply to all the traffic that matches the group membership criteria32

The log for a firewall rule on an ESXi transport node is stored in the /var/log/dfwpktlogs.log file. This file contains information about the packets that match or do not match the firewall rules, such as the source and destination IP addresses, ports, protocols, actions, and rule IDs. The log file can be viewed using the esxcli network firewall get command or the vSphere Client.

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-D57429A1-A0A9-42BE-A299-0C3C3546ABF3.html

According to the VMware Knowledge Base, this CLI command is used for packet capture on the ESXi node. pktcap-uw stands for Packet Capture User World and is a tool that allows you to capture packets from various points in the network stack of an ESXi host. You can use this tool to troubleshoot network issues or analyze traffic flows.

The other options are either incorrect or not available for this task. tcpdump is not a valid CLI command for packet capture on the ESXi node, as it is a tool that runs on Linux systems, not on ESXi hosts. debug is not a valid CLI command for packet capture on the ESXi node, as it is a generic term that describes the process of finding and fixing errors, not a specific tool or command. set capture is not a valid CLI command for packet capture on the ESXi node, as it does not exist in the ESXi CLI.

https://kb.vmware.com/s/article/2051814

Federation is a feature of NSX that allows the administrator to manage multiple NSX instances with a single pane of glass view, create gateways and segments that span one or more locations, and configure and enforce firewall rules consistently across locations1. Federation provides centralized policy management for security and networking services for all locations and pushes it down to NSX Local Managers at the respective sites for enforcement1. Federation also enables disaster recovery and workload mobility scenarios by providing consistent network and security policies across different sites1. References: 1: NSX Federation - VMware Docs(https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-D5B6DC79-6733-44A7-8072-50221CF2122A.html)

According to the VMware NSX Documentation, these are two of the use cases for Distributed Intrusion Detection, which is a feature of NSX Network Detection and Response:

Quarantine workloads based on vulnerabilities: You can use Distributed Intrusion Detection to detect vulnerabilities in your workloads and apply quarantine actions to isolate them from the network until they are remediated.

Identify security vulnerabilities in the workloads: You can use Distributed Intrusion Detection to scan your workloads for known vulnerabilities and generate reports that show the severity, impact, and remediation steps for each vulnerability.
