The SNC Nominal Route is the default or preferred route that is assigned to an LSP when it is created. The SNC Nominal Route is determined by the constraints that are specified by the user during the LSP creation process, such as cost, SRLG, color, bandwidth, protection, and regeneration. The user can modify the SNC Nominal Route in NFM-T by using the Constraint Wizard, which is a tool that allows the user to change the constraints for an existing LSP. The Constraint Wizard will then compute a new SNC Nominal Route based on the modified constraints and update the LSP accordingly34. References:

3: Nokia GMPLS-controlled Optical Networks Course | Nokia

4: Nokia Network Functions Manager for Transport User Guide | Nokia

The Upstream Label Object in RSVP-TE is an optional object that allows a node to suggest a label to its upstream neighbor for the purpose of provisioning bidirectional LSPs. The upstream label object is carried in the Resv message and contains the label value that the node wants to use for receiving traffic from its upstream neighbor. The upstream neighbor can accept or reject the suggested label based on its local policy and resource availability. The upstream label object simplifies the label allocation process for bidirectional LSPs and avoids the need for additional signaling messages. References : RSVP-TE - Hewlett Packard Enterprise, RSVP - Nokia

Constrained Shortest Path First (CSPF) is an extension of the shortest path first (SPF) algorithm that is used to find the best path for a Label Switched Path (LSP) in a GMPLS network. CSPF takes into account additional constraints such as bandwidth, latency, priority, or node or link inclusion or exclusion. CSPF works by pruning those links that do not meet the specified constraints and then applying the SPF algorithm to the remaining links. This way, CSPF can find a path that satisfies both the shortest distance and the constraints. References : Constrained Shortest Path First - Wikipedia, Constrained Shortest Path First (CSPF) - Metaswitch

 The Wait for Server Restoration (WSR) parameter in the MRN is a boolean parameter that determines whether an LI service should wait for the LO restoration or not in case of a failure.When WSR is false, the LI services do not wait for the LO restoration and restore through LI switching. This means that if an LO optical channel fails, the LI services that use that channel will switch to another available optical channel at LI layer without waiting for the LO layer to restore the failed channel. This option provides faster restoration time for LI services, but may result in suboptimal resource utilization at LO layer. When WSR is true, the LI services wait for the LO restoration and do not switch at LI layer. This means that if an LO optical channel fails, the LI services that use that channel will remain in that channel until the LO layer restores it or until a timeout occurs. This option provides optimal resource utilization at LO layer, but may result in longer restoration time for LI services. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3. GMPLS - Nokia

The Soft Shutting Down state in the NFM-T is an administrative maintenance state where services stay up but no new traffic can be routed over the TE-link. This state is used to prepare a TE-link for maintenance or decommissioning without affecting the existing services. The NFM-T sets the TE-link to Soft Shutting Down state by sending a Notify message with the Administrative State Change flag to the head-end node of the TE-link. The head-end node then stops accepting new LSP requests over the TE-link and sends a PathErr message with the Administrative State Change flag to all the tail-end nodes of the LSPs in the TE-link. The tail-end nodes then stop sending new traffic over the LSPs and send a ResvErr message with the Administrative State Change flag to all the intermediate nodes of the LSPs. The intermediate nodes then update their routing tables and stop forwarding new traffic over the LSPs. The existing traffic, however, continues to flow over the LSPs until they are manually deleted or rerouted by the NFM-T. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, Nokia Advanced Optical Network Management with NFM-T Course | Nokia

The Link Maintenance window is a feature of NFM-T that allows the user to perform maintenance tasks on links and nodes in a GMPLS network. The Link Maintenance window is a wizard that provides commands to set links and nodes to maintenance mode, which prevents them from being used for routing new LSPs or carrying traffic. The user can also use the Link Maintenance window to reroute existing LSPs away from the links and nodes that are in maintenance mode, either manually or automatically. The Link Maintenance window helps the user to perform network maintenance operations without disrupting the service availability or quality12. References:

1: Nokia GMPLS-controlled Optical Networks Course | Nokia

2: Nokia Network Functions Manager for Transport User Guide | Nokia

The GMPLS technology includes three categories of protocols: routing, signaling, and link management. Routing protocols are used to exchange information about the network topology, resources, and constraints among the nodes. Signaling protocols are used to establish, modify, and release Label Switched Paths (LSPs) across the network. Link management protocols are used to verify the connectivity and status of the links between adjacent nodes. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3. GMPLS - Nokia

Tunnel Property Heritage is a feature of GMRE that allows the propagation of certain properties from higher order (HO) LSPs to lower order (LO) LSPs in a multi-layer network. These properties include cost, SRLG, and color. Cost is a metric that reflects the preference of using a certain link or path for routing. SRLG is a set of links that share a common risk of failure. Color is an attribute that can be used to group or filter LSPs based on service classes or customer profiles. By propagating these properties from HO to LO LSPs, GMRE can ensure that the end-to-end LSPs are consistent and optimal across different layers34. References:

3: Nokia GMPLS-controlled Optical Networks Course | Nokia

4: GMPLS - Nokia

The 3R resource is a type of optical regeneration resource that can be used to extend the reach of optical signals in a GMPLS-controlled optical network. The 3R resource performs three functions: reshaping, retiming, and reamplifying the optical signal. The 3R resource can be added to the Network Planning Application (NPA) in the Nokia Network Functions Manager for Transport (NFM-T) through the Constraint Wizard. The Constraint Wizard is a tool that allows the user to define various constraints and parameters for the network design, such as optical impairments, wavelength availability, protection schemes, and regeneration resources. The user can select the 3R resource from the list of available resources and specify its location, capacity, and cost. The NPA then uses this information to perform feasibility checks and path computation for the LSP requests12. References:

1: Nokia GMPLS-controlled Optical Networks Course | Nokia

2: Nokia Network Functions Manager for Transport User Guide | Nokia

To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in a network with only LI restoration capability, you need to check the Logical Link box, set the Port Type to Unterminated, uncheck the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option is not needed for LI restoration, as the LSPs are established by NFM-T and not by GMPLS. The ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms - NATO
