Pass the Nutanix Certified Professional (NCP) NCP-MCI-6.5 Questions and answers with ExamsMirror

Virtual NIC receive packet dropped is the most useful VM metric for isolating the cause of users being disconnected from remote desktop sessions to a specific VM. This metric shows the number of packets that are dropped by the virtual NIC of the VM due to insufficient buffer space or other reasons. Packet drops can indicate network congestion, misconfiguration, or performance issues that can affect the quality and availability of remote desktop sessions. Packet drops can also cause retransmissions, delays, and errors in TCP-based protocols such as RDP2. To view this metric in Prism, go to Entities > Compute & Storage > VMs > Summary View and select a VM. Then, in the Details View, go to Metrics > Performance and select Virtual NIC receive packet dropped from the drop-down menu3.

According to the Nutanix Support & Insights web search result1, the administrator can change the frequency of checks and alerts for the System Non-Root Partition Usage in Prism Element by going to the Health Dashboard > Manage Checks > Schedule. The administrator can select the check name, such as disk_usage_check, and click on Edit Schedule. The administrator can then choose the desired frequency, such as every 15 minutes, every hour, or every day, and click on Save. This will change how often the check runs and alerts are generated.

The task that needs to be performed when time is not synchronizing properly after deploying a cluster is NTP configuration. In the Nutanix Multicloud Infrastructure (NCP-MCI) 6.5, Network Time Protocol (NTP) is used to synchronize the system time across all the nodes in a cluster. If the time is not synchronizing properly, it indicates that there might be an issue with the NTP configuration. Therefore, checking and correcting the NTP configuration would be the appropriate action to resolve this issue. The other options like DNS configuration, HA configuration, and SMTP configuration are not directly related to time synchronization in a cluster.

A native VLAN is a VLAN that is assigned to untagged traffic on a trunk port of a switch. A trunk port can carry traffic from multiple VLANs, but it needs to have a native VLAN to handle traffic that does not have a VLAN tag. The native VLAN is usually VLAN 1 by default on most switches, but it can be changed to any other VLAN number2. When creating a network profile on Nutanix, the administrator needs to specify the VLAN ID that matches the VLAN configuration on the physical switch. However, if the network profile uses the same VLAN ID as the native VLAN on the switch, it will cause network connectivity issues for the VMs connected to that network profile. This is because Nutanix AHV uses 802.1Q tagging for all network traffic, including traffic in the native VLAN. The switch will expect untagged traffic in the native VLAN and will drop any tagged traffic in that VLAN3. To fix this issue, the administrator needs to change the VLAN field from vlan. 1 to vlan. 0 in the network profile on Nutanix. This will tell Nutanix AHV to send untagged traffic for that network profile and match the native VLAN configuration on the switch4.

The cluster time zone is a setting that determines the time zone used by all CVMs in the cluster. The cluster time zone affects the timestamps of Nutanix logs, events, alerts, and reports. The cluster time zone also affects the scheduling of tasks such as snapshots, replication, and upgrades. By default, the cluster time zone is set to UTC (Coordinated Universal Time) when the cluster is created3.

To change the cluster time zone, the administrator needs to use the ncli (Nutanix command-line interface) on any CVM in the cluster. The steps are as follows4:

Log in to any CVM using SSH.

Run ncli cluster get-timezone to check the current cluster time zone.

Run ncli cluster set-timezone timezone= to change the cluster time zone, where  is a valid time zone identifier (for example, America/New_York).

Run ncli cluster get-timezone again to verify that the cluster time zone has been changed.

Note that changing the cluster time zone does not affect the time zone of Prism Element or Prism Central VMs. To change their time zone, the administrator needs to use Prism Element UI or Prism Central UI respectively5.

The correct answer is C. Network latency.

The diagram shows a solution that uses synchronous replication between two remote protection domains, cluster site A and cluster site B. Synchronous replication is a feature that allows near-zero RPO (recovery point objective) by replicating data to the remote site before acknowledging writes to the local site. However, synchronous replication has some requirements and limitations that must be met for it to work properly. One of these requirements is that the network latency between the two sites must be less than or equal to 5 ms1. If the network latency is higher than 5 ms, the synchronous replication will fail and the protection policy will be suspended2.

Therefore, based on the diagram, the most likely cause of the issue is that the network latency between cluster site A and cluster site B is higher than 5 ms, which prevents the synchronous replication from working. To verify this, the administrator can use the “ncli cluster ping” command to measure the network latency between the two sites3. If the network latency is indeed higher than 5 ms, the administrator can either improve the network performance or switch to a different replication mode, such as near-synchronous or asynchronous.

Answer: A. VM-VM anti-Affinity policy

A VM-VM anti-Affinity policy is a rule that ensures that two or more VMs don’t run on the same AHV host. It’s useful when an application provides HA and an AHV host can’t be an application’s single point of failure1. In this case, the SQL cluster VMs should have a VM-VM anti-Affinity policy configured to prevent them from running on the same host and causing an outage if that host fails. A VM-VM anti-Affinity policy can be created using the aCLI commands2. The other options are not relevant for this scenario.

References: 1: Affinity Policies - Nutanix Support & Insights 2: Affinity Policies Help | Nutanix Community

When a VM is connected to a Nutanix managed network, the IP address is assigned when the VM is powered on. A Nutanix managed network is a network that is created and managed by Prism Central using IP address management (IPAM). IPAM allows Prism Central to automatically assign IP addresses to VMs from a pool of available addresses in a subnet. IPAM also tracks the IP address usage and availability across clusters and networks4.

When a VM is connected to a Nutanix managed network, the administrator can choose one of the following assignment types for the IP address:

Assign Static IP: This option allows the administrator to manually specify a static IP address for the VM from the subnet range. The IP address will not change unless the administrator changes it.

Assign with DHCP: This option allows Prism Central to dynamically assign an IP address for the VM from the subnet range using DHCP. The IP address may change depending on the DHCP lease time and availability.

No Private IP: This option allows the administrator to skip assigning an IP address for the VM. This option is useful for scenarios where the administrator wants to use an external IPAM solution or assign an IP address later5.

Regardless of the assignment type, the IP address is assigned when the VM is powered on. This is because Prism Central needs to communicate with the hypervisor (AHV or ESXi) to configure the virtual NIC (vNIC) of the VM with the IP address information. This communication can only happen when the VM is in a powered on state6.

References: 4: IP Address Management - Prism Central Guide 5: Creating a New Report - Prism Central Guide 6: IP Address Assignment - AHV Networking Guide

According to the web search results, the cluster redundancy factor (RF) determines how many copies of the cluster metadata and configuration data are stored on different nodes. By default, the cluster RF is 2, which means that there are three copies of the Zookeeper and Cassandra data on the cluster. If the cluster RF is increased to 3, then there will be five copies of the Zookeeper and Cassandra data on the cluster12. This means that the Zookeeper component can tolerate two failures, as it can still operate with a quorum of three nodes out of five3.

However, the container replication factor (RF) determines how many copies of the VM data and oplog are stored on different nodes. The container RF can be set independently for each container, and it can be different from the cluster RF. For example, a container can have RF 2 even if the cluster has RF 34. In this case, the container will only have two copies of the VM data and oplog on the cluster, regardless of the cluster RF. This means that the Extent Groups component can only tolerate one failure, as it needs at least one copy of the VM data and oplog to be available5.

Therefore, if the administrator increases the cluster RF to 3, but does not modify the containers, then the new values in the data resiliency dashboard will be Zookeeper = 2 and Extent Groups = 1.
