NAT processing in Junos OS follows a strict sequence to ensure correct packet handling:

Static NAT– applied first because it provides a permanent one-to-one bidirectional mapping.

Destination NAT– applied second to translate inbound destination addresses, often used for servers in private networks.

Source NAT– applied last to translate outbound private source addresses to public ones.

This ensures deterministic behavior and avoids conflicts between translation types.

Options B, C, and D list incorrect sequences.

Correct Order:static NAT → destination NAT → source NAT

Global security policies extend the flexibility of policy enforcement across the SRX. They are not tied to specific source and destination zones:

From-zone and to-zone contexts are not required(Option A). Global policies apply across all zones unless restricted by match conditions.

Global security policies do not require specific zone contexts(Option B is incorrect).

Global policies areprocessed after zone-based policies, not before. This means that zone-based security policies take precedence (Option C is incorrect).

Administrators can configure bothzone-based security policies and global security policies at the same timeon the same device (Option D is correct).

This allows flexible designs where specific policies can be enforced by zone, while general policies can be applied globally without duplicating rules across multiple zones.

By default, SRX 300 Series Firewalls come with predefined security policies:

Trust-to-Untrust (Option B):A default policy exists to permit all traffic from thetrust zone to the untrust zone.

Trust-to-Trust (Option D):Intra-zone traffic is permitted by default; hence, a trust-to-trust policy is installed automatically.

Untrust-to-Trust (Option A):Not allowed by default, since external traffic must be explicitly permitted by an administrator.

Management-to-Trust (Option C):No such default policy exists.

Correct Policies:Trust-to-Untrust and Trust-to-Trust

In Juniper SRX flow-based packet processing, theflow moduleis responsible for security functions such as screening, session management, NAT, and policy enforcement. The processing order is critical:

Screens are applied before any session lookup.This ensures that packets are inspected for anomalies, floods, or protocol violations before consuming resources for session management. Examples of these screens include TCP SYN flood protection, ICMP flood protection, and port scanning protection.

After screening, thesession lookupoccurs. At this point, the firewall checks whether the packet belongs to an existing session in the session table. If a matching session is found, the packet bypasses policy evaluation and is forwarded according to the session state.

If no existing session is found, the packet continues throughroute lookup, NAT processing, and security policy evaluationbefore a new session is created.

Thus,screening occurs before the session lookup, protecting the system early in the flow process. This design ensures efficiency by dropping malicious or malformed traffic before allocating session resources.

From the exhibit:

The internal host (172.25.11.101) is located in theTrust zone.

The external address (203.0.113.199/30) is used for communication with the ISP.

The requirement is thatsessions can only be initiated from the external device(the ISP or untrust side) toward the internal host.

This requirement matches the behavior ofDestination NAT:

Destination NAT only (Option A):Maps the external/public IP (203.0.113.199) to the internal/private IP (172.25.11.101). This allows inbound connections to be translated and sent to the internal host. The internal host cannot initiate outbound sessions, since the translation only applies to inbound traffic.

Source NAT only (Option B):Used for outbound sessions from internal private IPs to the Internet. This does not meet the requirement.

Static PAT (Option C):Maps a single port of a public IP to a private IP/port. The exhibit does not indicate a port-based translation.

Static NAT and source NAT (Option D):Would provide bidirectional communication, allowing sessions to be initiated in both directions. This contradicts the requirement.

Correct NAT Type:Destination NAT only

To verify and demonstrate the effectiveness of content filtering on an SRX firewall, administrators use operational mode commands that display UTM statistics.

The commandshow security utm content-filtering statisticsprovides detailed counters showing how many connections were inspected, how many were blocked, and other related metrics.

This is the correct way to measure and demonstrate filtering effectiveness.

Commands in options A, B, and C provide status information for antispam, antivirus, and web filtering features, but they do not provide content filter effectiveness statistics.

Intra-zone traffic:On SRX devices, traffic between interfaces in the same security zone is allowedwithout requiring a security policy(Option C is correct). Policies are only evaluated for inter-zone traffic.

Junos-host functional zone:This zone is a predefined functional zone that allows administrators to apply policies controlling access to the SRX firewall itself, such as SSH, HTTP, or SNMP traffic (Option D is correct).

Null zone:This zone is a predefined discard zone. Interfaces placed in the null zone drop all traffic. It does not allow policy logging of dropped control plane traffic (Option A is incorrect).

Management functional zone:This is used to define management interfaces, not the “functional zone” as stated in Option B (incorrect wording).

Correct Statements:C and D

On SRX Series Firewalls, Junos OS automatically createssystem-defined zonesthat have special functions:

Null zone (Option A):A predefined discard zone. By default, all interfaces belong to the null zone until assigned to a user-defined zone. Traffic destined to the null zone is dropped.

Junos-host zone (Option B):A predefined functional zone that allows security policies to control traffic directed to the SRX device itself (management traffic, such as SSH, HTTP, SNMP).

Management zone (Option C):There is a predefinedmanagement functional zone, but it is not called "management" as a system-defined security zone.

DMZ (Option D):A DMZ zone must be explicitly created by the administrator, it is not system-defined.

Correct Zones:null, junos-host

Exception traffic is traffic that must be sent from the Packet Forwarding Engine (PFE) to the Routing Engine (RE) for processing, such as routing protocol updates, management traffic, or other control-plane packets. Because the RE is a limited and critical resource, Junos OS implementsrate limiting on exception traffic.

The purpose is toprevent denial-of-service (DoS) attacks on the Routing Engineby controlling the amount of traffic directed to it.

This ensures the RE continues to process control-plane operations reliably, even under potential attack or heavy traffic conditions.

Rate limiting does not enhance forwarding plane performance (Option A), simplify interface configuration (Option B), or manage routing protocols directly (Option D).
